| AMD FX-8150 Bulldozer Processor |
| Reviews - Featured Reviews: Processors | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Written by David Ramsey | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Wednesday, 12 October 2011 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
AMD FX-8150 Bulldozer CPU ReviewThe days when AMD processors ruled the performance roost are long gone, and most enthusiasts have forgotten they ever existed. But less than a decade ago, the Athlon X2 dual-core processor thoroughly spanked Intel's first crude dual-core efforts, which were simply two separate processor dies on one chip, communicating through the front-side bus, as opposed to AMD's much more advanced true dual-core CPUs. But AMD's been playing catch-up since then, and has been forced to compete on price rather than performance in desktop processors. Now Benchmark Reviews tests the high end of the new Bulldozer desktop CPU line, the multiplier-unlocked 8-core FX-8150 CPU. Enthusiasts have been slow to adopt multi-core CPUs beyond dual cores. Few software used them (especially games), and while extra cores could help a system running multiple applications, only a few individual applications could really leverage the extra power provided by multiple cores. But multi-core processor penetration in the market is increasing: while the largest percentage of users in the Steam hardware survey use only dual-core processors (47.6% as of August, 2011), four-core CPUs are close behind at 43.5%. Beyond four cores, the numbers drop off dramatically. Only 1.45% are using six-core processors, and 0.07% have 8 cores (and most of these are probably dual four-core processors). So the FX-8150 has an open market...
I've been a fan of AMD processors for some time, unbothered by their performance deficit relative to Intel since we've long since passed the point where almost any processor is more than fast enough for anything most people would want to do, and AMD simply offered better bang for the buck. But AMD's got a tougher challenge this time in Intel's new Sandy Bridge processors, not to mention the upcoming Sandy Bridge E series and Ivy Bridge. AMD already cedes the high end to Intel when they say the FX-8150 is designed to compete against the Core i7 2500K CPU rather than the top-end 2600K, but even that will be a strong competitor: it's even less expensive, at $219.99 at Newegg compared to the FX-8150's MSRP of $245.00.
Manufacturer: Advanced Micro Devices Full Disclosure: The product sample used in this article has been provided by AMD. AMD FX-8150 FeaturesThe following information is courtesy of AMD
AMD FX CPU SpecificationsAMD's consumer CPU line now has three main divisions: the E series APUs, which are aimed at netbooks, small notebooks, and tablets; the A series APUs for desktops and higher-end laptops (Benchmark Reviews tested the AMD A8-3850 "Lynx" CPU in this review), and the top-of-the-line FX processors. Unlike Intel's Sandy Bridge CPUs, all of which have integrated video, the FX CPUs are just CPUs. AMD expects you to add a Radeon 6000 series card to an FX system. The following chart shows the specifications of all the desktop-level FX-series processors. At launch, only the FX-8150, FX-8120, FX-6100 and FX-4100 will be available.
AMD's initial lineup of FX CPUs includes three eight-core chips, one six-core chip, and three four-core chips. Aside from core count and clock speed, the chip specifications are similar, with the main difference being that the amount of L2 cache is lower for the six and four-core CPUs. All FX CPUs are unlocked, so you'll be able to tweak clock speeds to the limits your hardware can handle. A surprisingly high DDR3-1866 memory speed should help bandwidth, assuming you have memory that can run at that speed. AMD's Turbo Core technology will use the maximum speed if only half or fewer of the cores are in use; if all cores are in use, Turbo Core is dialed back to keep the CPU within its thermal limits. With the new AM3+ socket come three new chipsets: the 990FX, the 990X, and the 970X, all supported by the SB950 south bridge. All the new chipsets provide six SATA 6G ports, 12 USB 2.0 ports, and RAID levels 0, 1, 5, and 10. The only difference is in the supported PCI-E configuration: 2x16 or 4x8 for the 990FX, 2x8 for the 990X, and 1x16 for the 970X. Benchmark Reviews covered the 990FX chipset in our review of the ASUS Crosshair V Formula motherboard. Obviously, the exciting thing about the FX-8150 is that it's the first consumer eight core processor. Prior to the AMD FX, if you wanted an eight-core CPU you had to buy a very expensive server-level Xeon or Opteron chip, and then you'd have to deal with things like the special "registered" memory these CPUs require, and an expensive server motherboard lacking many of the features expected in enthusiast-level motherboards...like, say, overclocking. (Yes, I know about the Intel Skulltrail and EVGA SR2 motherboards. But they're the exception.) But will eight cores really make a difference? Well, that's what we're here to find out. In the next section I'll go into the details of the Bulldozer processor architecture. Bulldozer CPU ArchitectureTechnically, the term "Bulldozer" refers to the two-core module that AMD uses as a building block for its new processors. Desktop CPUs built with Bulldozer modules are code-named "Zambezi", while server processors built with Bulldozer modules are "Interlagos" for CPUs designed for single and dual processor systems, and "Valencia" for processors designed for four or more CPU systems. Here's a block diagram of a Bulldozer module:
Each module comprises two integer execution units and one floating point execution unit. All three units share the instruction fetch and decoders, as well as the L2 cache, but each core has its own instruction scheduler and L1 cache. Each module can handle two concurrent threads (one on each integer unit), so AMD considers a single Bulldozer module to be "dual core." But is this an accurate description? Intel supplies this labeled die image for Sandy Bridge processors:
Note that there are four areas labeled "Core". For comparison, here's a labeled die image for a quad-module (8 cores) AMD Bulldozer CPU:
Here, there are four areas labeled "Bulldozer module", and as we saw above, each module has two cores. But what does a "core" consist of? In Sandy Bridge, each core contains three Arithmetic Logic Units (ALUs) and two Address Generation Units (AGUs). AMD's Phenom II CPU has three ALUs and three AGUs per core, while a Bulldozer "integer core" has two ALUs and two AGUs, for a total of four ALUs and four AGUs per module. (The floating point execution unit is a separate entity. Since floating point instructions comprise only a small percentage of most code, the single FPU in a Bulldozer module is shared.) An Arithmetic Logic Unit does the actual work of handling the instruction, be it a conditional, bit rotate, add, or other integer operation. The Address Generator Unit handles address generation, and to explain that would involve getting deep into Intel address architecture, which is beyond the scope of this article. Suffice it to say that the AGU is needed for everything from figuring out the real address of that branch destination to where to put the results of a given calculation to translating between virtual memory addresses and physical addresses. Keeping these units "fed" are the instruction schedulers, which decide how to dispatch instructions that have been fetched from memory and decoded. A Phenom II core can issue 3 ALU or AGU instructions per clock; Sandy Bridge can issue 3 ALU/1 AGU or 2 ALU/2 AGU instructions per clock (four total), while Bulldozer can issue 2 ALU/2 AGU per clock (also for a total of four). Note that while the Phenom II core has the most ALUs/AGUs (6 total), it can issue the fewest instructions per clock (three, as opposed to four for Sandy Bridge and Bulldozer). There are other differences: each Sandy Bridge core has its own floating point unit, while a Bulldozer module has two integer units (the ALUs) and only a single floating point unit. So the eight core FX-8150 has four floating point units, just like the four-core Sandy Bridge. Since the vast majority of program instructions will be handled by the integer ALUs, this shouldn't affect real-world performance...but our benchmarks will show if this is the case. Complicating comparisons further are things like decode queues, instruction pipelines, branch prediction, thread retirement, cache management, and more. Modern processors are hideously complex; long gone are the days when a programmer could figure out exactly how long a segment of code would take to execute by simply adding up the number of clock cycles required for each instruction and figuring the time based on the CPU clock frequency! (Yes, we really used to do that.) Bulldozer adds further optimizations: for example, if only one integer core is being used, it has access to all the resources on the module, such as the cache: there's nothing "reserved" for the idle core. AMD has also finally caught up with some of Intel's new features, like AES-NI for ultra-fast encryption and decryption, Advanced Vector Instructions (AVX), and a 32nm fabrication process (which will hopefully help with overclocking). AMD also has some new instructions of their own: the FMA (floating point multiply-accumulate) and XOP instructions. The former allows fast multiply-and-add sequences, which turn out to be useful in video transcoding, among other things. The XOP instructions are an extension to SSE5 that AMD announced back in 2009 and consist of new integer vector instructions, such as integer vector multiply-accumulate and integer vector compare; the Bulldozer CPUs are the first implementation of XOP. All of these features sound really cool when AMD's technical and marketing folks are giving the presentations. But unless you're a CPU architect (and I'm not), it's impossible to judge their real-world impact on paper. And while I'm convinced some of AMD's new internals are very advanced, Intel's made some enormous strides with Sandy Bridge, especially in the crucial "instructions per clock" metric. Simply put, this means that at the same frequency as previous generation Intel CPUs, Sandy Bridge is significantly faster. And of course many Intel processors support Hyper-Threading, which doubles the number of available cores (as far as software is concerned), so that a four-core processor appears as an eight-core processor. AMD claims that eight real cores should provide better performance than four real and four virtual cores; while this makes sense, AMD is positioning the FX-8150, the top of the Zambezi desktop processor lineup, against the non-HyperThreading 2500K rather than the Hyper-Threading capable Core i7-2600K. Well, all this makes for interesting arguments in bars, but what really matters is the performance. So let's get on with the testing. Processor Testing MethodologyFor this test Benchmark Reviews is fortunate to have two high-end 990FX motherboards: AMD supplied an ASUS Crosshair V Formula with a pre-installed FX-8150, and MSI supplied their new 990FXA-GD80. Benchmark Reviews examined the ASUS Crosshair V Formula motherboard here, and a detailed review of the MSI 990FXA-GD80 will follow shortly. Although I tested the AMD FX-8150 in both motherboards, all the overclocking and performance measurements for this article were done on the ASUS motherboard. For comparison purposes I also used an AMD Phenom II X6-1100T six core CPU, AMD's previous top of the line part. Representing the Intel camp is what AMD considers the FX-8150's competition: a Core i5 2500K CPU, in this case installed in an ASUS P8Z68V Pro motherboard. Although I used the same memory for both Intel and AMD tests (a G. Skill 4GB kit rated at up to 2133MHz), I set the memory speed to the maximum officially supported by each CPU/chipset: 1333MHz in the case of the Intel system and the 1100T, and 1866MHz for the AMD FX-8150 systems. The memory timings were 9-9-9-24 in all cases. Different overclockers have different techniques. For example, AMD's recent 8.4gHz world record overclock of the FX 8150 represented the maximum speed at which they could successfully boot into Windows and run CPU-Z. Other overclockers go for the maximum single-core overclock. I prefer to aim for the highest speed at which I can run all cores under load. The FX 8150, like the Intel Sandy Bridge CPUs, uses a 32nm fabrication process, and reaped similar overclocking benefits: on the ASUS Crosshair V Formula motherboard, I was able to hit 4.8gHz on all cores at 1.4V and complete all my benchmarks. This helped performance significantly, but the Core i5 2500K can be overclocked, too...and coincidentally my test 2500K hit its highest stable overclock at the same 4.8GHz frequency as the FX-8150! The overclocked results for both processors are included in all the benchmark tests. Intel Z68 Test Platform
AMD 990FX Test Platforms
Benchmark Applications
AIDA64 Extreme Edition TestsAIDA64 Extreme Edition is the evolution of Lavalys' "Everest Ultimate Edition". Hungarian developer FinalWire acquired the rights to Everest in late November 2010, and renamed the product "AIDA64". The Everest product was discontinued and FinalWire is offering 1-year license keys to those with active Everest keys. AIDA64 is a full 64-bit benchmark and test suite utilizing MMX, 3DNow! and SSE instruction set extensions, and will scale up to 32 processor cores. An enhanced 64-bit System Stability Test module is also available to stress the whole system to its limits. For legacy processors all benchmarks and the System Stability Test are available in 32-bit versions as well. Additionally, AIDA64 adds new hardware to its database, including 300 solid-state drives. On top of the usual ATA auto-detect information the new SSD database enables AIDA64 to display flash memory type, controller model, physical dimensions, and data transfer performance data. AIDA64 v1.00 also implements SSD-specific SMART disk health information for Indilinx, Intel, JMicron, Samsung, and SandForce controllers. All of the benchmarks used in this test— Memory reads and writes, Queen, Photoworxx, ZLib, hash, and AES— rely on basic x86 instructions, and consume very little system memory while also being aware of Hyper-Threading, multi-processors, and multi-core processors. Of all the tests in this review, AIDA64 is the one that best isolates the processor's performance from the rest of the system. While this is useful in that it more directly compares processor performance, readers should remember that virtually no "real world" programs will mirror these results. Although I'm using the same physical memory on both the AMD and Intel systems, I'm running it at different speeds: the officially supported maximum on each platform, which is 1333MHz for the Intel Core i5 and AMD Phenom II 1100T, and DDR3-1866 for the FX-8150. Let's see how this plays out in AIDA64's memory throughput tests:
And...not that well. While the FX-8150 shows a huge improvement in memory throughput over its predecessor, the Core I5 2500K still easily wins, even doubling the write throughput performance. This is an interesting result considering the higher frequency of the FX-8150 memory subsystem.
The Queen and Photoworxx tests are synthetic benchmarks that iterate the function many times and over-exaggerate what the real-world performance would be like. The Queen benchmark focuses on the branch prediction capabilities and misprediction penalties of the CPU. It does this by finding possible solutions to the classic queen problem on a chessboard. At the same clock speed theoretically the processor with the shorter pipeline and smaller misprediction penalties will attain higher benchmark scores. Like the Queen benchmark, the Photoworxx tests for penalties against pipeline architecture. The synthetic Photoworxx benchmark stresses the integer arithmetic and multiplication execution units of the CPU and also the memory subsystem. Due to the fact that this test performs high memory read/write traffic, it cannot effectively scale in situations where more than two processing threads are used, so quad-core processors with Hyper-Threading have no real advantage. The AIDIA64 Photoworxx benchmark performs the following tasks on a very large RGB image:
The Intel processor produces the highest scores in both benchmarks, but the differences are interesting: at stock clocks speeds, the 2500K and FX-8150 are neck and neck, with the 1100T actually very slightly in the lead. Overclocking the Intel results in a decisive win, with the Intel CPU coming in about 18% above the AMD. In the Photoworxx benchmark, the FX-8150 is much faster than the 1100t, even faster than its two extra cores would lead you to believe. The Intel processor still wins, although not by as large a margin as it did in the Queen benchmark, and the very high overclocks for both processors produce only minor improvements in their scores.
In the ZLib test, the AMD CPUs leap ahead of the Intel 2500K, with even the previous-generation 1100T beating the stock-clocked 2500K. In the Hash test, the difference is even more profound: the Intel CPU simply can't keep up with the AMD CPUs here. Intel's Clarksdale and subsequent CPUs have dominated the AES test due to their Advanced Encryption Standard New Instructions (AES-NI), which dramatically accelerate AES code. AMD's own implementation of AES-NI makes its first appearance in Bulldozer-based CPUs, and in the ASUS motherboard turns in slightly better scores than the Intel CPU, although the score in the MSI motherboard is, oddly, about 11% lower. Overclocking has a minimal effect on this benchmark in either case, and the Phenom II X6-1100T, which does without AES-NI, just can't compete.
So far, we've seen the Intel and AMD CPUs slug it out and swap wins in these tests. Let's move on to the PCMark Vantage benchmark. PCMark Vantage TestsPCMark Vantage is an objective hardware performance benchmark tool for PCs running 32- and 64-bit versions of Microsoft Windows Vista or Windows 7. It's well suited for benchmarking any type of Microsoft Windows Vista/7 PC: from multimedia home entertainment systems and laptops, to dedicated workstations and high-end gaming rigs. Benchmark Reviews has decided to use a few select tests from the suite to simulate real-world processor usage in this article. Our tests were conducted on 64-bit Windows 7, with results displayed in the chart below. TV and Movies Suite
Gaming Suite*
Music Suite
* EDITOR'S NOTE: Hopefully our readers will carefully consider how relevant PCMark Vantage is as a "real-world" benchmark, since many of the tests rely on unrelated hardware components. For example, per the FutureMark PCMark Vantage White Paper document, Gaming test #2 weighs the storage device for 100% of the test score. In fact, according to PCMark Vantage the video card only impacts 23% of the total gaming score, but the CPU represents 37% of the final score. As our tests in this article (and many others) have already proven, gaming performance has a lot more to do with the GPU than the CPU, and especially more than the hard drive or SSD (which is worth 38% of the final gaming performance score).
The TV and Movies suite concentrates on video playback and transcoding, but only uses two threads at a maximum, so the extra cores of the AMD processors shouldn't be an advantage. The FX-8150 is less than 4% slower than the 2500K, but overclocking the Intel CPU adds enough performance to significantly increase this lead, while overclocking the FX-8150 leads to a relatively small performance gain. The Gaming benchmark relies on the hard disk and video card for over 50% of its score (see the Editor's Note above), and we're using the same HDD and video card for all platforms, so the Intel processor's decisive win in this test simply means that Vantage's gaming code is more optimized for Intel processors. Bear in mind, however, that most "real world" games will not show this difference; generally, in games, your video card matters most, followed by the clock speed (not number of cores) of your processor. The PCMark Vantage gaming test can use up to 16 threads, so it's very strange that the eight core FX-8150 turns in markedly lower scores than the six core 1100T. Unlike the Gaming test, the Music test results have more real-world relevance, since multi-threading is much more common in music transcoding applications than it is in games. Even so, the four core Intel CPU beats the six and eight core AMD processors. The wins are piling up in the Intel column. Let's move on to CINEBENCH. CINEBENCH R11.5 BenchmarksMaxon CINEBENCH is a real-world test suite that assesses the computer's performance capabilities. CINEBENCH is based on Maxon's award-winning animation software, Cinema 4D, which is used extensively by studios and production houses worldwide for 3D content creation. Maxon software has been used in blockbuster movies such as Spider-Man, Star Wars, The Chronicles of Narnia, and many more. CINEBENCH Release 11.5 includes the ability to more accurately test the industry's latest hardware, including systems with up to 64 processor threads, and the testing environment better reflects the expectations of today's production demands. A more streamlined interface makes testing systems and reading results incredibly straightforward. The CINEBENCH R11.5 test scenario comprises three tests: an OpenGL-based test that models a simple car chase, and single-core and multi-core versions of a CPU-bound computation using all of a system's processing power to render a photo-realistic 3D scene, "No Keyframes", the viral animation by AixSponza. This scene makes use of various algorithms to stress all available processor cores, and all rendering is performed by the CPU: the graphics card is not involved except as a display device. The multi-core version of the rendering benchmark uses as many cores as the processor has, including the "virtual cores" in processors that support Hyper-Threading. The resulting "CineMark" is a dimensionless number only useful for comparisons with results generated from the same version of CINEBENCH. For this test I used only the multi-core rendering benchmark. All AMD processors beat the 2500K at stock clock speeds, but overclocking leads to another win for Intel, although by a mere 7%.
Looking at the results, we see a four core processor holding its own or beating six and eight core processors. The obvious conclusion is that Intel gets more done "per core" than does AMD. Later in this review I'll take a closer look at single core performance. For now, it's on to CPU dependent 3D gaming.
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Base | Single Core Max | L1 Cache | L2 Cache | L3 Cache | DDR3 Freq | |
| FX-8150 | 3.6GHz | 4.2GHz | 128K | 2M (shared per module) | 2M (shared per module) | 1866MHz |
| Phenom II 1100T | 3.3GHz | 3.7GHz | 128K | 512K | 6M (shared) | 1333Mhz |
| Core i5 2500K | 3.3GHz | 3.7GHz | 64K | 256K | 6M (shared) | 1333Mhz |
Comparisons between differing core architectures are inherently imprecise. Recall that Bulldozer modules each comprise two integer cores and one shared floating point core, and that if only a single integer core (APU) is in use, it can use all of the normally shared cache resources. For these tests I used benchmarks that had "number of threads" settings and set the number of threads to "1". First up is the CINEBENCH single core rendering test.
Intel dominates here. While the FX-8150 could leverage its eight core to roughly match the 2500K in multi-core rendering, it's no contest at the single core level.
\
And Intel's domination continues in single-core renderings using Blender and POV-Ray. Let's look at Passmark:
AMD leads in three of these four tests, including, oddly, the integer test. Intel traditionally beats AMD in integer performance, so I can't explain this result, especially given the very large 70% delta.
But the FX-8150 falls behind again in three of the last four Passmark tests.
Note that in most of these tests, the spiffy new Bulldozer cores in the FX-8150 provide about the same performance as the Thuban cores in the Phenom II X6-1100T. This is disappointing especially given the base and turbo frequency advantage enjoyed by the new processor. But AMD has one more trick up their sleeve: new x86 instructions that applications can use to increase performance.
AMD FX New Instructions
The basic "x86 instruction set" has been with us since the eight-bit Intel 8080 processor was introduced in 1974. Since then, both Intel and AMD have introduced extensions to the x86 instructions like MMX, SSE, 3D Now, and so forth. In the Bulldozer, AMD has added these instructions:
- AES New Instructions-- Originally introduced by Intel, these instructions dramatically accelerate AES encryption.
- AVX-- Advanced Vector Extensions enhance floating point performance.
- FMA4 and XOP-- New instructions for complex math, useful in rendering and video transcoding applications.
The problem with new instructions is that existing programs won't benefit, since the instructions didn't exist at the time the programs were built. New instructions require support from compiler vendors, who must upgrade their products to generate the new code when appropriate (or directed by the programmer). Current benchmarks and applications will not benefit from these new instructions, but new ones will.
To demonstrate the performance improvements possible with these new instructions, AMD provided recompiled versions of x264HD using the new AVX and XOP instruction features. Both the 2500K and the FX-8150 support AVX instructions, but the 1100T does not.
For the first two runs, Intel wins, although if you compare the FX-8150's Run 1 scores against its scores in the standard x264HD benchmark, you'll see a 61% improvement, from 75fps to 120.61fps. Intel improves too, from 93.42 to 150.7fps, which is also a 61% improvement. In Run 2, the performance deltas are similar.
AMD pulls ahead in Runs 3 and 4, but the improvements in frame rates over the standard x264 benchmark are minimal. Now, let's look at the results from x264HD coded with the XOP instructions.
Since the XOP instructions are currently unique to the Bulldozer, the Sandy Bridge processor and the 1100T cannot run this benchmark at all. However, the scores returned for the FX-8150 are virtually identical to the ones returned by the AVX version of the benchmark in the first two runs.
The pattern repeats itself in Runs 3 and 4. The scores for the FX-8150 are about the same as they were for the AVX version of the benchmark.
AMD says that current Microsoft compilers incorporate the switches to enable code generation for these instructions. Based on this single benchmark, they can provide significantly improved performance that dramatically narrows Intel's performance lead.
AMD FX-8150 Overclocking
Like Intel's Sandy Bridge, AMD's new Bulldozer processors are fabricated on a 32nm process. This means they use less power and generate less heat than the older Phenom II CPUs, which were based on a 45nm process. Less power and less heat generally means better overclocking, and the FX-8150 doesn't disappoint: I was able to reach a stable 4.8GHz on all eight cores under extended stress testing, running the CPU at 1.4V and using a Thermalright Silver Arrow air cooler. This is 200MH higher than AMD suggested was feasible for all cores "on air" in their reviewer's guide, so I feel pretty good about it! With the giant Thermalright Silver Arrow cooler, processor temperatures under load maxed out at 59 degrees at an ambient temperature of 24 degrees.
Overclockers were initially dismayed that Intel's Sandy Bridge and its supporting Cougar Point chipset removed two classic overclocking mechanisms: increasing the base clock speed and increasing the base multiplier. You can only overclock Sandy Bridge CPUs by increasing the turbo multiplier, and then only on a "K" series Sandy Bridge CPU and a supported motherboard chipset. Somewhat ameliorating these limitations was the fact that if you did have the right hardware, Sandy Bridge CPUs were capable of immense overclocks.
AMD's FX series CPUs, in contrast, are completely unlocked and the 990FX chipset does not generate the base clock for the entire system, so you have all the classic overclocking mechanisms available. Now, for most real world use, overclocking by raising the turbo multiplier is your best bet: the CPU will ramp up its clock speed under load as needed, but drop back to a lower clock speed when it's idling, using less power and generating less heat. But for my tests I wanted to be sure that the Bulldozer was pushing with its blade all the way down under all circumstances, so I raised the base multiplier to 24, which when multiplied by the 200MHz base clock resulted in a speed of 4.8GHz. I did try a 24.5 multiplier, and I could boot and run at 4.9 but the system would crash under stress testing.
The chart below shows how overclocking affected the 8150's performance on each benchmark, with the stock clocked benchmark score normalized to 1.0 and the overclocked benchmark score represented as how much faster it was than the base clocked benchmark.
| 8150 Stock | 8150 OC | |
| AIDA64 Memory Read | 1.0 | 1.02 |
|
AIDA64 Memory Write |
1.0 | 1.05 |
| AIDA64 Queen | 1.0 | 1.20 |
| AIDA64 Photoworxx | 1.0 | 1.05 |
| AIDA64 AES | 1.0 | 1.00 |
|
AIDA64 ZLIB |
1.0 | 1.14 |
| AIDA64 Hash | 1.0 | 1.14 |
| CINEBENCH Single Core | 1.0 | 1.13 |
| CINEBENCH Multi Core | 1.0 | 1.19 |
| Passmark CPU Marks | 1.0 | 1.24 |
| PCMark Vantage TV/Movies | 1.0 | 1.05 |
| PCMArk Vantage Gaming | 1.0 | 1.11 |
| PCMark Vantage Music | 1.0 | 1.04 |
| Street Fighter IV | 1.0 | 1.12 |
| Handbrake 0.95 | 1.0 | 1.16 |
| x264HD Run 1 | 1.0 | 1.21 |
| x264HD Run 2 | 1.0 | 1.19 |
| x264HD Run 3 | 1.0 | 1.18 |
| x264HD Run 4 | 1.0 | 1.17 |
| SPECviewperf Lightwave | 1.0 | 1.13 |
| SPECviewperf Maya | 1.0 | 1.10 |
| SPECviewperf TCVIS | 1.0 | 1.16 |
| SPECapc Lightwave Interactive | 1.0 | 1.09 |
| SPECapc Lightwave Multitasking | 1.0 | 1.15 |
| SPECapc Lightwave Rendering | 1.0 | 1.20 |
| Blender/Icetest | 1.0 | 1.24 |
| POV-Ray | 1.0 | 1.13 |
| Average Performance Improvement | 13.3% | |
The performance improvement is less than what I'd hoped, but bear in mind that the AMD FX-8150 can crank its cores up to 4.2GHz at stock clock speeds, and the difference between 4.2GHz and 4.8GHz is only 14.9%, so the observed 13.3 percent is quite close to what you'd expect from the clock speed difference.
Late note: AMD will be selling the FX-8150 in a kit bundled with a water cooler. Although there isn't an MSRP yet, AMD says the price will be "about $100" more than the CPU by itself. Benchmark Reviews received the water cooler too late to incorporate into this review, but we'll be investigating its performance in a future article.
Bulldozer Final Thoughts
Those of us hoping that AMD's Bulldozer CPUs would catapult ahead of Sandy Bridge performance must live with the disappointment. Considered on its own, the AMD FX-8150 CPU is a great processor with excellent performance (especially if you can keep all eight cores busy), and in many cases beats the Intel Core i5 2500K. But there are few real-world applications that gamers and enthusiasts use that will fully exploit it; in fact, as you can see from many of these benchmarks, even programs designed to spawn multiple threads frequently do not scale their performance well past four cores.
Of course, having eight cores also means you can have a lot of background stuff going on and still keep things perky in the foreground application, and AMD has some persuasive demo videos showing how much smoother multitasking is with real cores as opposed to virtual cores, but it's a hard thing to quantify.
The 32nm fabrication process and other architecture improvements give the FX-8150 good overclocking headroom, and AMD's aggressive turbo frequencies represent the first officially-supported 4GHz and higher clock speed in any consumer CPU. But the Core i5 2500K has lots of overclocking headroom, too. Since overclocking results aren't guaranteed, the comparison chart below is based on each CPU's scores at stock clock speeds.
| Stock clocked performance results | Core i5 2500K score | FX-8150 score | FX-8150 % Diff |
| CINEBENCH single | 1.5 | 1.01 | -33% |
| CINEBENCH multi | 5.45 | 5.93 | +8.8% |
| SPECviewperf Maya | 14.86 | 9.71 | -14.9% |
| SPECviewperf TCVIS | 7.44 | 5.05 | -32% |
| SPECviewperf LightWave | 31.83 | 26.43 | -17% |
| SPECapc multitasking (lower is better) | 1389 | 1351 | -2.7% |
| SPECapc interactive (lower is better) | 535 | 674 | +26% |
| SPECapc rendering (lower is better) | 871 | 792 | -9% |
| AIDA64 Memory Read | 16508 | 13838 | -16% |
| AIDA64 Memory Write | 18341 | 10255 | -44% |
| AIDA64 Queen | 32278 | 31702 | -1.8% |
| AIDA64 PhotoWorxx | 52548 | 46598 | -11.3% |
| AIDA64 Zip | 198 | 262 | +32.3% |
| AIDA64 AES | 375440 | 380271 | +1.3% |
| AIDA64 Hash | 2071 | 3677 | +77.5% |
| Vantage TV & Movies | 5988 | 5753 | -3.9% |
| Vantage Gaming | 11787 | 6173 | -47.6% |
| Vantage Music | 11017 | 9901 | -10.1% |
| Street Fighter IV low-res (fps) | 568 | 410 | -27.8% |
| Handbrake (times in secs, lower is better) | 146 | 127 | +15% |
| x264Bench HD Run 1 | 93 | 75 | -19.4% |
| x264Bench HD Run 2 | 97 | 75 | -22.7% |
| x264Bench HD Run 3 | 29 | 36 | +24.1% |
| x264Bench HD Run 4 | 29 | 36 | +24.1% |
| PassMark CPUMark | 6987 | 8657 | +23.9 |
| Blender/icetest rendering time (lower is better) | 112 | 118 | -5.1% |
| POV-ray rendering time (lower is better) | 269.29 | 214.06 | +25.8% |
Using these benchmarks, the stock-clocked AMD FX-8150 averages 2.2% slower than the stock-clocked Intel Core i5 2500K. But as you can see looking at this chart, the individual differences are typically much higher: the FX-8150 tends to win big or lose big. It would be easy to choose a mix of benchmarks that gave a decisive win to either CPU, but I tried to use as broad an array of tests as I could to give the most accurate performance comparison.
As I showed in the single-core section, the performance of a Bulldozer core is not significantly better than the performance of the older AMD Thuban core, and both are far behind a Sandy Bridge core, so AMD's banking on keeping all eight cores filled to get the best performance. And indeed the FX-8150 can return excellent performance in these cases, although the performance improvement is less than what you might expect given the extra cores. And if software vendors upgrade their products to use the new instructions AMD has integrated into Bulldozer, its performance will improve more.
AMD claims the Windows 7 thread scheduler doesn't make the best use of Bulldozer's architecture, and says that we can expect a 10-15% performance improvement when Windows 8 ships. Also, Bulldozer is just the first in a line of new processors: in the coming years we'll see Piledriver (2012), Steamroller (2013) and Excavator (2014), each of which AMD says will bring improvements in performance-per-watt and instructions-per-clock.
But Intel's not standing still. Before the end of the year we should see Sandy Bridge "E" processors, and next year we'll see the 22nm Ivy Bridge processors, which according to rumor will drop right into existing Cougar Point motherboards, enabling Intel users to easily upgrade their systems. AMD FX CPUs are only officially supported on AMD 9-series chipsets, although several vendors have said that their 8-series motherboards will support FX processors with a BIOS upgrade. When specifcally asked about this, AMD said only that official support is limited to the 9-series chipsets, but that individual vendors were free to do what they wanted. We'll see, I suppose.
Given the market for this processor, you might wonder why I didn't include game benchmarks. The reason is simple: at high resolutions (say 1080p and above) and with multi-monitor systems, the critical factor is your video card setup, not the processor. Assuming the same video card configuration, your Bulldozer gaming rig will not give you a noticeably different experience than your Sandy Bridge gaming rig. If you're an AMD fanboy like me, rest assured that a Bulldozer system is an excellent base on which to build a high end gaming rig.
A few weeks ago I attended an all-day press briefing on the Bulldozer architecture at AMD's Austin, Texas headquarters. One of the points AMD made was that performance is only one aspect of a processor; another is performance per watt. But while AMD's server processors and E- and A-series APUs excel in this area, the FX-8150's 125 watt TDP is 32% greater than the Core i5 2500K's 95 watts. Granted, most desktop system users don't consider processor power draw when designing a system, but there it is.
AMD's weakness remains its integer core (APU) performance, which Bulldozer does not significantly improve over Thuban. More cores can compensate for this in some circumstances, but overall in my tests the FX-8150 can be considered at best to have achieved performance parity with Intel's 2500K...at a $254 MSRP as compared to the 2500K's $216 MSRP.
AMD FX-8150 Conclusion
Benchmark tests should always be taken with a grain of salt. It's difficult to try and isolate the performance difference a single component in a computer system makes, especially when it's necessary to compare across different manufacturers and platforms. Complicating the matter is the fact that benchmarks change, a manufacturer may change the technical details of a product, and the retail price may change as well. So please use this review as just one piece of information, and do your research before making a buying decision.
AMD fans have been awaiting the Bulldozer for months, and while it represents a significant performance improvement over Thuban, I'm disappointed with its overall performance, especially the memory bandwidth and single-core performance. Prior to Sandy Bridge, the FX-8150 would have been a very competitive processor; now, the best you can say is that performance-wise it's as good, overall, as a Core i5 2500K. Except that the Intel processor costs about $35 less: and that's a sore point, because historically AMD processors tend to beat Intel in a "bang for the buck" competition due to their lower prices.
As of November 2011, the previous-generation "Thuban" 1100T six-core processor sells for a mere $190 while Bulldozer costs $269.99 at Newegg, so AMD fans will want to carefully consider if two more cores are worth another $64 and a new motherboard, especially given that the per-core performance is virtually the same between the Bulldozer and Thuban cores.
We can hope that Windows 8 and upgraded applications and utilities that use the new FX instructions will make it more competitive, and I'd expect these things right about the time Ivy Bridge become available.
Pros:
+ First consumer eight-core processor
+ Officially supports 4GHz-plus turbo speeds and DDR3-1866 memory
+ An FX system has 42 PCI-E lanes as opposed to the 24 lanes of a Sandy Bridge system
+ 990FX chipset supports NVIDIA SLI. Finally.
+ AMD finally has a 32nm processor with good overclocking
Cons:
- Requires a new Socket AM3+ motherboard- Single core performance has remained static
- Full performance requires Windows 8 system and applications that use its new instructions
- Overall similar performance to Core i5 2500K, but at a higher price
Ratings:
-
Performance: 8.00
-
Construction: 9.00
-
Overclock: 9.50
-
Functionality: 8.50
-
Value: 8.00
Final Score: 8.60 out of 10.
